4 Wheel Drive 140HP Tractor 1604

Overall Dimension (L×W×H):5220 *2380 *3250mm (to top of air filter)

Min. Operating Weight:6000 kg

Wheelbase:2750 mm

Wheel Track (Front/Rear):1750, 1850, 1950, 2050 / 1620–2420 mm

Application:
Features:

Share this:

Application Scenarios

Product Description

The 160HP SeekMach tractor comes with a 300L large dual fuel tank system, supporting long hours of continuous work.
It reduces downtime from frequent refueling and greatly improves overall operating efficiency.
The braking system uses hydraulic disc brakes, delivering strong braking force and great resistance to thermal fade.
It maintains stable braking performance even under long‑term heavy use, with simple and smooth operation.

The internal transmission structure is fully optimized with four‑stage reduction.
The final drive features a double‑cone and planetary reduction design, and the central transmission can be equipped with a differential lock as an option.
This makes power delivery more efficient and dependable.
The mid‑mounted cylinder works with an independent hydraulic steering system, ensuring equal turning radius on both sides.
The reasonable steering angle design allows flexible and accurate turning in the field.
With a maximum load capacity of 2600KG, the tractor has a rugged, durable structure and strong load‑bearing ability.
It can match all kinds of heavy agricultural implements.

The driving experience is greatly improved: the aviation‑grade widened air‑cushion seat increases comfort and safety.
The hydraulic‑assisted clutch pedal eases operation and reduces fatigue during long working hours.
The side‑mounted independent handbrake delivers stable parking and further enhances operation safety.
It also supports function expansion, with an optional limited‑slip differential for better performance on complex terrain.
It is a powerful machine for large‑scale farmland operations.

140HP Tractor Overview

The 140‑horsepower SeekMach tractor is designed for large‑scale paddy and dry field operations.
It features a flat‑floor ROPS cab and a mechanical suspension seat, with an air suspension seat available as an option.
You can choose engines from Quanchai, YTO, Yunnei, or Xinchai.
An additional diesel filter and cold‑start heating function ensure reliable starting even at temperatures as low as –20 °C.

Key Advantages

Key Features

Flat-Floor ROPS Cab
30% more legroom than traditional designs
Certified rollover protection, optional canopy
Mechanical/Air Suspension Seat
  • Shock-absorbing travel up to 100 mm
  • 150 kg driver weight range, all-day comfort
Multi-Brand 140 HP Engine
  • Euro II/III emission options
  • Extra water-separator + 10 μm diesel filter
  • 5-minute block heater for sub-zero starts
High-Performance Front Axle
  • IP67 waterproof seal, paddy-ready
  • 45°-50° steering angle, turning radius ≤ 4.3 m
  • Hydraulic hose linkage for 20% faster response
Farmland & Optional Radial Tires
14.9-28 / 18.4-38 bias-ply tires as standard
Radial or 12-ply engineering tires available

Optimized 1.6 speed ratio cuts slip by 12%

Technical Specifications (Schema-ready table)

Engine Power: 140 HP / 103 kW
PTO Speed: 540/1000 rpm (optional 760/1000)
Hydraulics: 3-point Cat II, 24 kN lift capacity
Steering: Hydrostatic, 45°-50° angle
Fuel Tank: 150 L (optional 180 L)
Weight: 4,050 kg (ballasted)
Dimensions: 4,550 × 2,180 × 2,780 mm

Why Choose Us

  • Located in Shandong, China’s largest agricultural machinery cluster
  • In-house R&D team, ISO 9001 & CE certified factory
  • Professional technicians provide 1-to-1 pre-sales consulting
  • Free spare parts in every shipment
  • 12-month full-machine warranty, 24-hour online service, lifetime technical support





Parameter

Category Item Specification
Dimensions & Weight Overall Dimension (L×W×H) 5220 *2380 *3250mm (to top of air filter)
Min. Operating Weight 6000 kg
Wheelbase 2750 mm
Wheel Track (Front/Rear) 1750, 1850, 1950, 2050 / 1620–2420 mm
Engine Model / Brand YTO YT0160HP 6-Cylinder Stage II
Type Vertical, water-cooling, four-stroke, common rail
Cylinder Count 6
Rated Power 160 HP / 117.7 kW
Rated Speed 2200 r/min
Drive Train Clutch Single disc, dry, independent control, dual stage
Gearbox TDF 16 Forward + 8 Reverse
Gear Shift Type Shift sleeve
Steering & Brake Steering Type Full hydraulic steering
Brake Type Hydraulic control, wet, disc
Walking Device Tire Size (Front/Rear) 12.4-24 / 16.9-34
Working Device Suspension Type Rear, three-point suspension, Category III
Adjustment Mode Height adjustment, floating control
Hydraulic Output Multi-way valve output
Standard PTO Speed 8 or 6 keys; 760/850 or 540/1000 rpm
Safety & Optional Protection Cabin (Standard)
Optional Equipment Swing traction, Quick suspension, Yuchai engine, 14.9-26/18.4-38 tires, Rear counterweight, 24+8 gearbox, TF front drive axle

Compatible Accessories

Scenes To Be Used

Farm Land

Wheat Field

Vegetable Garden

Dry Land

Application Scenarios
