Application Scenarios
Product Description
The 1004 Heavy-Duty SeekMach Tractor represents the peak of professional agricultural power.
It has a substantial 3900 kg operating weight for maximum traction and stability.
Powered by a high-torque YTO 6-cylinder engine, it delivers a consistent 100 HP.
It is specially designed for large-scale farming and heavy industrial hauling.
This flagship model uses an advanced TDF 16F+8R gearbox with shift sleeve technology.
It provides precise speed control for complex operating tasks.
With a reinforced chassis, 2240 mm extended wheelbase, and oversized 16.9-34 rear tires.
The 1004 heavy-duty version offers exceptional ground clearance and pulling power.
It performs reliably even in the most demanding soil conditions.
Key Advantages
High-Performance Power Plant
-
100 HP 6-cylinder YTO engine provides exceptional torque and power reserves for heavy-duty plowing.
-
High-pressure common rail technology ensures fuel efficiency and steady power output at a rated speed of 2200 r/min.
-
Independent control dual-stage clutch allows for separate operation of the drive train and PTO-driven implements.
Professional Heavy-Duty Chassis
-
Increased 3900 kg weight provides superior downforce, significantly reducing wheel slip during deep tillage.
-
Extended 2240 mm wheelbase ensures longitudinal stability when handling heavy rear-mounted attachments.
-
Adjustable wheel track (up to 2100 mm rear) offers maximum versatility for various row-crop widths and specialized farming.
Advanced Drive & Maneuverability
-
16 Forward + 8 Reverse gear configuration provides the industry’s most versatile speed range for all farming tasks.
-
Full hydraulic steering allows for effortless handling of this nearly 4-ton machine with precision and ease.
-
Wet disc braking system ensures reliable, heavy-duty stopping power even on steep or slippery slopes.
Exceptional Work Capability
-
Large 16.9-34 rear tires provide a massive contact patch for ultimate grip and high ground clearance.
-
Two groups of hydraulic outputs facilitate the use of multi-functional modern hydraulic farm tools.
-
Category II three-point suspension with floating control maintains precise depth for seeding and tillage implements.
Parameter
| Category | Item | Specification |
| Dimensions & Weight | Overall Dimension (L×W×H) | 4600 *2200 *2950mm |
| Min. Operating Weight | 3900 kg | |
| Wheelbase | 2240 mm | |
| Wheel Track (Front/Rear) | 1600–1950 / 1620–2100 mm | |
| Engine | Model / Brand | YTO YT0110HP Stage II |
| Type | Vertical, water-cooling, four-stroke, common rail | |
| Cylinder Count | 6 | |
| Rated Power | 100 HP / 73.5 kW | |
| Rated Speed | 2200 r/min | |
| Drive Train | Clutch | Single disc, dry, independent control, dual stage |
| Gearbox | TDF 16 Forward + 8 Reverse | |
| Gear Shift Type | Shift sleeve | |
| Steering & Brake | Steering Type | Full hydraulic steering |
| Brake Type | Mechanical control, wet, disc | |
| Walking Device | Tire Size (Front/Rear) | 7.5-20 / 16.9-34 |
| Working Device | Suspension Type | Rear, three-point suspension, Category II |
| Adjustment Mode | Height adjustment, floating control | |
| Hydraulic Output | 2 groups | |
| Standard PTO Speed | 8 or 6 keys; 760/850 or 540/1000 rpm | |
| Safety | Protection | ROPS (Roll-over protection structure) |
