Product Description
The 904 4WD SeekMach Tractor is a heavy-duty agricultural machine built for high-intensity farming and professional land management.
With an operating weight of 2967 kg and a 2045 mm wheelbase, it delivers outstanding stability for large-scale operations.
It is powered by a high-performance 90 HP (66.2 kW) Yangdong 4-cylinder engine with advanced common rail technology for efficient and reliable power.
Designed for superior versatility, the 904 model comes with a 12F+12R shift sleeve gearbox and full hydraulic steering for smooth and accurate control.
Its rear wheel track can be continuously adjusted from 1350 to 1600 mm, making it ideal for different row-crop planting conditions.
Equipped with a Category II three-point linkage, dual hydraulic outputs, and multi-speed PTO, this tractor can easily handle a wide variety of heavy-duty agricultural attachments.
Key Advantages
High-Capacity Power & Professional Performance
-
90 HP 4-cylinder common rail engine delivers massive torque for heavy-duty plowing and deep tillage.
-
12 Forward + 12 Reverse gears provide a wide range of speeds to optimize productivity across different soil conditions.
-
Dual-stage independent control clutch allows for seamless shifting without interrupting PTO-driven tasks.
Superior Stability & Adaptability
-
Steplessly adjustable rear wheel track ensures the tractor can be tailored to specific crop spacing and ridge widths.
-
Large tire configuration (9.5-24 / 14.9-30) combined with a heavy 2967 kg chassis ensures maximum traction and minimal slip.
-
Full hydraulic steering and wet disc brakes provide effortless handling and reliable stopping power for safe operation.
Advanced Implementation Support
-
Dual groups of hydraulic outputs enable the simultaneous control of complex, multi-functional attachments.
-
Versatile PTO options (up to 1000 rpm) ensure high compatibility with various high-speed rotating implements.
-
Category II three-point suspension with height and floating control provides precise depth management for tillage.
Customizable & Operator-Focused
-
Standard ROPS ensures operator safety, with the option to upgrade to a Luxury AC or Heating Cabin for year-round comfort.
-
Flexible engine and tire options allow the machine to be customized for specific regional farming needs.
-
Quick suspension and swing traction options are available to enhance efficiency during frequent implement changes and transport tasks.
Parameter
| Category | Item | Specification |
| Dimensions & Weight | Overall Dimension (LWH) | 4200 *1800 *2630mm |
| Min. Operating Weight | 2967 kg | |
| Wheelbase | 2045 mm | |
| Wheel Track (Front/Rear) | 1350 / 1350–1600 mm (Steplessly adjustable) | |
| Engine | Model / Brand | Yangdong Stage II |
| Type | Vertical, water-cooling, four-stroke, common rail | |
| Cylinder Count | 4 | |
| Rated Power | 90 HP / 66.2 kW | |
| Rated Speed | 2200 r/min | |
| Drive Train | Clutch | Single disc, dry, independent control, dual stage |
| Gearbox | 12F + 12R | |
| Gear Shift Type | Shift sleeve | |
| Steering & Brake | Steering Type | Full hydraulic steering |
| Brake Type | Mechanical control, wet, disc | |
| Walking Device | Tire Size (Front/Rear) | 9.5-24 / 14.9-30 |
| Working Device | Suspension Type | Rear, two-point suspension, Category II |
| Adjustment Mode | Height adjustment, floating control | |
| Hydraulic Output | 2 groups | |
| Standard PTO Speed | 8 or 6 keys; 760/850 or 540/1000 rpm | |
| Safety & Optional | Protection | ROPS (Roll-over protection structure) |
| Optional Equipment | Luxury AC cabin, heating cabin, swing traction, quick suspension, etc. |
