Custom 50HP Tractor Dealer SM-504G

Weight：1410 kg

Wheel Base：1510 mm

Overall Dimension (LWH)：2780 × 1260 × 2050 mm (to ROPS top)

Tires Size (4WD)：6.0-12 / 9.5-16

Application:

Features:

High-efficiency and energy-saving engine, compliant with international emission standards
Advanced hydraulic system, improving working efficiency by 30%
Ergonomic cab design, lowering operator fatigue
Intelligent monitoring system for real-time equipment status tracking
Sturdy structural parts for longer service life
Various working modes to suit different operation conditions

Application Scenarios

Product Description

The SeekMach 504G is a high-performance ultra-compact 4WD tractor built for professional agricultural work in tight spaces.
Despite its compact size, it is powered by a durable Laidong 495BT engine that delivers a strong 50 HP for heavy-duty tasks.
With a structural weight of 1410 kg and a maximum rated drawbar power of ≥10.6KN, it provides top-level traction in its class.

This tractor features an ultra-maneuverable design with an overall width of only 1260 mm and a shortened 1510 mm wheelbase.
It is perfectly suited for narrow orchards, vineyards, and greenhouses where space is limited.
The 8+2 gear transmission and hydraulic steering offer precise control.
The high-pressure lifter and 720 rpm PTO ensure high efficiency when using various agricultural attachments.

Key Advantages

Ultra-Compact Design for Tight Spaces

Narrow 1260 mm width allows for seamless operation in high-density orchards and narrow aisles.
Short 1510 mm wheelbase significantly reduces the turning radius for better maneuverability.
Low-profile dimensions (2780 mm length) make it perfect for restricted urban or indoor job sites.

Exceptional Power & Traction

Maximum rated drawing power of ≥ $ge 10.6text{ KN}$ provides superior pulling capacity for heavy implements.
50 HP Laidong engine delivers high torque while maintaining fuel efficiency under heavy loads.
4WD system ensures stable performance and maximum grip on uneven or slippery terrain.

Professional Working Efficiency

Strong pressure lifter enhances the lifting capability for various agricultural attachments.
720 rpm PTO speed is optimized for high-efficiency operation of specialized rotating tools.
Integrated front and rear ballast system ensures optimal weight distribution and stability.

Versatile & Durable Configuration

Hydraulic steering reduces operator fatigue during long working hours.
Optional ROPS and Canopy provide enhanced safety and operator comfort in different environments.
8 Forward + 2 Reverse gears offer a versatile speed range to match specific task requirements.

Parameter

Category	Item	Specification
Power System	Model	QL504G
	Driven Model	4WD
	Engine	LAIDONG 495BT
	Engine Power	50 HP
	Emission Standards	II stages
Transmission	Clutch	Single-stage type
	Gears	8 + 2
	Speed Range (km/h)	Forward: 2.06–31.30 / Reverse: 2.71–12.52
Performance	PTO Speed	720 rpm
	Max. Rated Drawing Power	$ge 10.6text{ KN}$
	Steering	Hydraulic steering
	Lifter	Strong pressure lifter
Dimensions	Weight	1410 kg
	Wheel Base	1510 mm
	Overall Dimension (LWH)	2780 × 1260 × 2050 mm (to ROPS top)
	Tires Size (4WD)	6.0-12 / 9.5-16
Equipment	Ballast	Front (7KG) + Rear (26KG one layer)
	Hydraulic Output	1 groups of hydraulic output
	Optional Equipment	ROPS, Canopy, Iron frame packaging
