Application Scenarios
Product Description
The 40 HP 4WD SeekMach Compact Tractor is a sturdy and high-performance agricultural machine built for tough farming and utility jobs in various conditions.
With a structural weight of 1,410 kg, it provides excellent stability and traction.
It delivers a maximum rated drawbar power of ≥8KN for heavy hauling, plowing, and landscaping work.
Powered by the reliable LAIDONG 4L23/KM490 engine, it generates 40 HP and meets Stage II emission standards.
The 8+2 gear transmission offers a wide speed range from 2.06 to 31.30 km/h.
The dual-speed PTO (540/720 rpm) with one set of hydraulic outputs supports compatibility with many professional attachments.
Its compact structure has an overall width of 1,400 mm and a 1,780 mm wheelbase.
It works efficiently in narrow spaces like orchards, vineyards, and greenhouses.
Equipped with hydraulic steering and front and rear ballast, it ensures precise control and improved balance.
It is a reliable choice for commercial farmers and specialized agricultural operations.
Key Advantages
Compact Design for Restricted Spaces
-
Narrow 1400 mm overall width is perfectly suited for orchards, greenhouses, and narrow farm lanes.
-
1780 mm wheelbase provides a stable platform while maintaining a compact footprint.
-
Ideal for restricted agricultural environments where high power is needed in limited spaces.
High-Efficiency Working Performance
-
Maximum rated drawing power of ≥8KN ensures superior towing and plowing capability.
-
Dual-speed PTO (540/720 rpm) improves the productivity of various rotating implements.
-
8 Forward + 2 Reverse gears offer a versatile speed range (2.06–31.30 km/h) to match specific tasks.
Reliable & Robust Power
-
Equipped with a LAIDONG 4L23/KM490 engine, recognized for its durability and steady torque.
-
40 HP output delivers high performance for demanding professional agricultural applications.
-
Stage II emission standards ensure stable operation and reliable mechanical performance.
Stable & Durable Undercarriage
-
4WD driven model provides enhanced grip and climbing ability on uneven or soft terrain.
-
6.5-16 front and 11.2-24 rear tires offer excellent ground clearance and stability.
-
Optimized weight distribution with front and rear ballast (one layer) ensures balance under heavy loads.
Easy Operation & Maintenance
-
Full hydraulic steering allows for effortless maneuverability and precise control.
-
1410 kg structural weight balances heavy-duty durability with ease of transport.
-
Single-stage clutch and a simple mechanical layout result in lower maintenance costs.
Parameter
| Category | Item | Specification |
| Power System | Driven Model | 4WD |
| Engine | LAIDONG 4L23/KM490 | |
| Engine Power | 40 HP | |
| Emission Standards | II stages | |
| Transmission | Clutch | Single-stage type |
| Gears | 8 + 2 | |
| Speed Range | Forward: 2.06–31.30 km/h | |
| Reverse: 2.71–12.52 km/h | ||
| Performance | PTO Speed | 540 / 720 rpm |
| Max. Rated Drawing Power | ≥8KN | |
| Steering | Hydraulic steering | |
| Dimensions | Weight | 1410 kg |
| Wheel Base | 1780 mm | |
| Overall Dimension (LWH) | 3350 * 1400 * 2000 mm | |
| Tires Size | 6.5-16 / 11.2-24 | |
| Attachments | Ballast | Front ballast and Rear ballast (one layer) |
| Hydraulic Output | 1 groups |
