The SeekMach 25 Mini Excavator is a heavy-duty and versatile construction machine built for high-performance excavation in professional job sites.
With an operating weight of 2500 kilogrammes, it delivers excellent stability and a ground pressure of 23 kPa, ideal for intensive earthmoving work.
Powered by premium engine options including the 22.1KW Laidong 385 ou the reliable Kubota D1703, the SeekMach 25 ensures stable power output with a large displacement of 1.617 L.
Its advanced TAITE hydraulic system, equipped with a GEAR 12/12/04 pump and 24/24 L/min flow rate, offers smooth and precise control for accurate site preparation.
Designed for high productivity, the SeekMach 25 comes with a large 45 L fuel tank to support long working hours.
With an outstanding maximum digging radius of 3600 mm and a digging depth of 2000 mm, it provides the extended reach needed for deep trenching and efficient material handling.
It keeps a compact chassis width of 1300 mm for excellent performance in confined spaces.
Principaux avantages
Compact Design for Professional Spaces
-
châssis étroit 1300 millimètres and a short platform tail slewing radius of 950 mm.
-
Ideal for urban construction projects and restricted professional environments.
Performances de creusement efficaces
-
Profondeur de creusement maximale de 2000 millimètres.
-
Extended digging radius of up to 3600 mm.
-
Hauteur de déversement de 2200 millimètres significantly improves loading efficiency.
Reliable & High-Output Power
-
Equipped with powerful engine options like the Laidong 385 (18,8 kW) or Kubota D1703 (18.2 KW).
-
High rated power of 22.1 KW balances heavy-duty performance with fuel efficiency.
Châssis stable et durable
-
245 millimètres largeur de voie et 1890 mm total track length.
-
Enhanced stability and low ground pressure (23 kPa) on uneven terrain.
Extended Operation & Heavy-Duty Build
-
Grand 45 L fuel tank capacity for long working hours.
-
Robuste 2500 kilogrammes operating weight with a maximum digging force of 12 kN.
Paramètre
| Catégorie | Paramètre | spécification |
| Performance Parameters | Poids opérationnel | 2500 kilogrammes |
| Canopy/Cabin | Canopée | |
| Capacité du seau | 0.06 m³ | |
| Bucket Width | 400 mm | |
| Max. digging force | 12 kN | |
| Arm digging force | 5 kN | |
| Moteur | Marque/Modèle | Laidong 385 (18.8KW) / Kubota D1703 (18.2KW) / Yanmar 3TNV80F (15.2KW) |
| Rated power/speed | 22.1KW/2200RPM | |
| Déplacement | 1.617 L | |
| Système hydraulique | Main Pump Brand | TAITE |
| Pump type | GEAR 12/12/04 | |
| débit | 24/24 L/min | |
| Swing motor | TAITE 400 cc | |
| Traveling motor | 200 cc | |
| Movement & Capacity | Running speed (high/low) | 2.8 km/h |
| Max. traction | 12 kN | |
| Pente | 30° | |
| Capacité du réservoir de carburant | 45 L | |
| Hydraulic oil tank capacity | 30 L | |
| Scope of Work | Max. digging height | 3200 mm |
| Max. dumping height | 2200 millimètres | |
| Max. digging depth | 2000 millimètres | |
| Max. digging radius | 3600 mm | |
| Max. lift height of the dozer blade | 210 millimètres | |
| Max. digging depth of the dozer blade | 150 mm | |
| Outline Dimensions | Overall Dimension (LxWxH) | 3100X1300X2350 mm |
| Longueur totale de la piste | 1890 mm | |
| Platform tail slewing radius | 950 mm | |
| Largeur de châssis | 1300 millimètres | |
| Largeur de la piste | 245 millimètres |
