Scenari applicativi

Descrizione del prodotto
IL SeekMach 1304 Heavy-Duty Tractor is a flagship agricultural machine built for high-intensity, professional farming operations.
With an operating weight of 4726 kg and an extended 2500 mm wheelbase, it provides superior traction and stability for the most demanding field work.
It is powered by a high-performance 6-cylinder YTO engine rated at 130 HP, using advanced common rail technology to deliver consistent power for heavy plowing and large-scale hauling.
This model is equipped with a professional TDF 16F+8R shift sleeve gearbox, providing a wide range of speeds to maximize efficiency.
Its heavy-duty Category III three-point suspension E dual-speed PTO ensure excellent compatibility with modern agricultural attachments.
Combining strength and precision, the SeekMach 1304 is the ideal choice for efficient large-scale farming.
Vantaggi principali
Superior Flagship Power
-
130 HP 6-cylinder YTO engine provides massive torque reserves for the most challenging soil conditions.
-
High-pressure common rail technology delivers steady power output while maintaining efficiency at 2200 r/min.
-
Dual-stage independent control clutch ensures seamless operation of the tractor and PTO-driven implements simultaneously.
Maximum Stability & Traction
-
Heavyweight 4726 kg chassis offers superior downforce to minimize wheel slip during heavy towing.
-
Long 2500 mm wheelbase ensures excellent longitudinal stability when using large, rear-mounted implements.
-
Adjustable wheel track (up to 2210 mm rear) allows for precise adaptation to various ridge widths and farming techniques.
Advanced Implementation Support
-
Category III three-point suspension provides the high lifting capacity required for professional-grade tillage equipment.
-
16 Forward + 8 Reverse gear configuration provides the most detailed speed matching for diverse agricultural tasks.
-
Dual groups of hydraulic outputs allow for the simultaneous control of complex, multi-functional hydraulic attachments.
Enhanced Maneuverability & Comfort
-
Sterzo completamente idraulico allows for effortless handling of this nearly 5-ton machine with high precision.
-
Wet disc braking system provides reliable, heavy-duty stopping power under various weather and terrain conditions.
-
Luxury AC or Heated Cabin options create a controlled environment for year-round productivity in extreme weather.
Parametro
| Categoria | Articolo | Specifica |
| Dimensions & Weight | Overall Dimension (L×W×H) | 4600 *2200 *2950mm |
| Min. Operating Weight | 4726 kg | |
| Wheelbase | 2500 mm | |
| Wheel Track (Front/Rear) | 1440–1740 / 1610–2210 mm | |
| Motore | Model / Brand | YTO YT0130HP 6-Cylinder Stage II |
| Tipo | Vertical, water-cooling, four-stroke, common rail | |
| Cylinder Count | 6 | |
| Potenza nominale | 130 HP / 95.6 kW | |
| Rated Speed | 2200 r/min | |
| Drive Train | Frizione | Single disc, dry, independent control, dual stage |
| Cambio | TDF 16 Forward + 8 Reverse | |
| Gear Shift Type | Shift sleeve | |
| Steering & Brake | Steering Type | Sterzo completamente idraulico |
| Brake Type | Hydraulic control, wet, disc | |
| Walking Device | Tire Size (Front/Rear) | 7.5-20 / 16.9-34 |
| Working Device | Suspension Type | Rear, three-point suspension, Category III |
| Adjustment Mode | Height adjustment, floating control | |
| Uscita idraulica | 2 gruppi | |
| Standard PTO Speed | 8 or 6 keys; 760/850 or 540/1000 rpm | |
| Safety & Optional | Protection | ROPS (Standard) |
| Optional Equipment | Luxury AC cab, heated cab, swing traction, quick hitch, rear counterweight, propulsion engine |
